The Versatile Nature of Aramid Fibers
Aramid fibers are a class of heat-resistant and strong synthetic fibers. They are thermoplastic polymers which were first introduced commercially in the early 1960s. The name "Aramid" is a portmanteau of "aromatic polyamide". They are used in aerospace and military applications, protective clothing like coats and gloves, optical fiber cables, friction materials and more.
Structure and properties
Aramid fibers are made through a solution spinning process where concentrated sulfuric acid is used as a solvent to dissolve polyamide polymers. The chain segments within the polymer form ordered regions which allow the molecules to pack tightly together for enhanced strength. This crystalline structure provides its unique properties.
Aramid Fibers is high strength-to-weight ratios and moduli. Their strength is around three times higher than steel on an equal weight basis. They also have excellent heat resistance and do not burn or melt easily. They can withstand continuous use temperatures up to approximately 300°C. Their outstanding thermal stability is due to the aromatic chemical structure which has bonds that are difficult to break at high temperatures. Another useful property is their low density which makes them lighter than most materials of comparable strength like steel or glass fiber.
Applications
Bulletproof vests and other protective clothing
They are commonly used in bulletproof vests and tactical clothing due to their high strength and excellent resistance to impact. The strong fibers effectively stop penetration of projectiles using their energy absorption ability. Their light weight also enhances comfort for the wearer. They used in firefighting apparel and industrial protective clothing provide protection from heat, flames and impact hazards.
Aircraft components
The strength, heat resistance and light weight of aramid fibers make them suitable for aircraft and aerospace applications. They are used to make composite structures in aircraft and helicopters that must withstand extreme environmental conditions. Aramid reinforced plastics are used in fuselages, wings, rotor blades and other load-bearing components.
Friction materials
They find application in brake pads and clutch facing materials that require high tensile strength, dimensional stability at elevated temperatures and low wear properties. Their strength transmits braking forces efficiently while heat resistance preserves performance under repeated high temperature uses.
Optical fiber cables
Telecommunication optical fiber cables use aramid yarns for reinforcement and strength members as aramid fibers endure tensile loads without stretching or breaking. The material's high tensile strength, light weight and resistance to moisture damage make them suitable for this application.
Industrial filter fabrics
Aramid fabrics are used as filter mats or meshes in the chemical, pulp and paper industries. Their strength holds the filter shape while heat resistance allows use under high temperature conditions. Good chemical resistance also makes them appropriate industrial filter materials.
Tire reinforcement
They are available as cords that provide high strength reinforcement properties to tires. They improve handling and load-bearing ability of tires without adding substantial weight. The heat resistance of aramid yarns allows them to perform efficiently under extreme tire operating conditions.
Military applications
Owing to their excellent mechanical properties, they find extensive use in body armor, helmets, ballistic blankets and reinforcement in armored vehicles. The high specific strength and energy absorption of these fibers helps combat ballistic threats effectively. Low signature properties also make them suitable for military camouflage nets.
Processing and properties of different types
There are several commercial types of aramid fibers based on the kind of polyamide used and manufacturing method. Key ones are:
- Para-aramid: Made from poly-paraphenylene terephthalamide (PPD-T), branded as Twaron or Kevlar by different manufacturers. They have very high tensile strength but low elongation. Used in ballistic protection equipment and industrial sewing threads.
- Meta-aramid: Manufactured from poly-metaphenylene isophthalamide (PMIA), examples being Technora and Novax. These have lower strength compared to para-aramids but better resistance to impact and abrasion making them suitable for applications like cut-resistant gloves.
- Copolyamides: Made using a blend of ortho- and para-benzenediamine which gives improved properties compared to para-aramids. Examples include Technora which offers tear and cut resistance as well as strength retention at high temperatures.
- Poly-p-phenylene-2,6-benzobisoxazole (PBO): A super high strength and high modulus fiber available as Zylon. It has initial strength greater than para-aramids but is susceptible to strength loss when exposed to high humidity. Used in special high-performance applications.
- Other liquid crystal polymer fibers like Vectran have properties in between conventional aramid and ultra-high molecular weight polyethylene fibers. They have high strength, flexibility and durability.
Aramid fibers introduced a new class of high-performance fibers with outstanding strength, heat resistance and light weight properties. Their versatility has led to a wide range of applications from military to automotive to industrial uses. Continuous research and development aims to improve fiber properties to overcome humidity-based strength loss issues and broader market adaptability. Aramid fibers are surely a revolutionary material that enhanced safety, engineering capabilities and opened new possibilities.
