Integral Flanged Gate Valve

China Integral Flanged Gate Valve Manufacturer: Class 150LB, Class 300LB, Class 600LB Integral Flanged Gate Valve, 1/2-2 Inch, API 602, ASME BI6.34, BS 5352.

Design Construction:
API 602, ASME BI6.34, BS 5352
Testing according to API 598
Face to face according to ASME B16.10
Flanges according to ASME B16.5
Marking MSS SP25
Spiral-wound gasket
Integral backseat
Integral body flanges
Outside Screw and Yoke (OS&Y)
Self aligning two piece packing gland

Ratings:
-carbon steel class 150 285 psig@ 100°F 20 bar + 38°C
-carbon steel class 300 740 psig@ 100°F 51 bar + 38°C

150LB	NPS	Dimensions(mm)
	NPS	A	B	C
	1/2	108	90	150
	3/4	117	95	160
	1	127	105	170
	1-1/2	165	120	200
	2	178	150	250

300LB	NPS	Dimensions(mm)
		A	B	C
	1/2	140	90	150
	3/4	152	95	160
	1	165	105	170
	1-1/2	190	120	200
	2	216	150	250

600LB	NPS	Dimensions(mm)
	NPS	A	B	C
	1/2	165	90	150
	3/4	190	95	160
	1	216	105	170
	1-1/2	241	120	200
	2	292	150	250

Price

China Integral Flanged Gate Valve Manufacturer: Class 150LB, Class 300LB, Class 600LB Integral Flanged Gate Valve, 1/2-2 Inch, API 602, ASME BI6.34, BS 5352.

150LB	NPS	Dimensions(mm)
	NPS	A	B	C
	1/2	108	90	150
	3/4	117	95	160
	1	127	105	170
	1-1/2	165	120	200
	2	178	150	250

300LB	NPS	Dimensions(mm)
		A	B	C
	1/2	140	90	150
	3/4	152	95	160
	1	165	105	170
	1-1/2	190	120	200
	2	216	150	250

600LB	NPS	Dimensions(mm)
	NPS	A	B	C
	1/2	165	90	150
	3/4	190	95	160
	1	216	105	170
	1-1/2	241	120	200
	2	292	150	250
